Icom IC-718
| Type:
|
Amateur HF Transceiver |
| Frequency Range: |
TX: 10-160 m + WARC
RX: 0.030-30 MHz |
| Modes: |
SSB/CW/AM |
| RF Power output: |
SSB/CW: 5-100 W
AM: 2-40 W |
| Sensitivity: |
N/A |
| Selectivity: |
N/A |
| Image rejection: |
N/A |
| Voltage: |
13.8 VDC |
| Current Drain: |
RX: Max 2 A
TX: Max 20 A |
| Aerial Input: |
50 ohms, SO-239 |
| Dimensions (W*H*D): |
240*95*239 mm |
| Weight: |
3.8 Kg |
| Manufactured: |
2000-200x |
| Other: |
101 memories |
| Related Documents: |
User Manual (3.9 MB)
Brochure (281 Kb) |
 |
